| System | Main Processor | GK7102C |
| Image sensor | GC1034/F37 | |
| Operation System | Embedded LINUX OS system | |
| Video | Resolution | 720P |
| Video Compression | Smart H.264+ | |
| P/T Range | Horizontal:355° ; vertical: 90° | |
| Object tracking | Support | |
| Illumination | 0.1LUX/F1.2 | |
| Picture Capture | Support | |
| Video Flip | Support | |
| Audio | Coding standard | G.711 |
| Two-way audio | Support | |
| Record management | Video file size | 2.5GB-4.5GB/Day |
| Record Mode | Manual record, motion detection record, scheduled record, alarm record | |
| Video storage | TF Card/Cloud | |
| Playback, back up | Support | |
| Alarm trigger | Video Push、Alarm recording、screen shot capture ,sending Email | |
| Network | Network Interface | default without RJ45 Port |
| WIFI | 802.11b/g/n | |
| Stream | Dual Stream | |
| Network Protocol | Support TCP/IP、RTSP、ONVIF, etc | |
| Transmission mode | P2P ,Cloud Sever | |
| Connection | Sweep QR code，AP Hotspot | |
| Extend | Storage | Maximum support 128GB TF card |
| Reset key | Support | |
| Power | Power input | DC 5V 1.5A |
| Power consumption | 6W | |
| Working Environment | Suitable occasion | Home,shop,School,factory |
| Installation mode | Flat put、Wall mounted、hoisting | |
| Working Temperature | -20℃－＋55℃ | |
| Working humidity | 10%－90% | |
| Others | Camera lens | 3.6MM |
| View Angle | 90° | |
| Lamp board | 6pcs Infared leds | |
| Product size | 67*85*105 (mm) |
